HZ-2109A Vertical Digital Leather Measuring Machine

The HZ-2109A vertical digital leather measuring machine uses infrared digital scanning for accurate area measurement. Its compact footprint, simple operation and low single-phase power consumption suit tanneries, footwear factories and furniture manufacturers.

Technical specifications:

1. Working width: 180 cm; custom widths are available.

2. Dimensions: 90 × 230 × 110 cm.

3. Working speed: 25 m/min.

4. Motor power: 0.75 kW.

5. Measurement repeatability: within ±1% over ten accumulated measurements of the same reference plate.

6. Stepless calibration.

7. Dot-matrix printer with Chinese/English output.

8. Units: square feet, traditional Chinese square feet and square metres.
