HZ-2121 Constant-Temperature Oil Bath Tester

The HZ-2121 constant-temperature oil bath tester evaluates the oil resistance of enameled wire, rubber, footwear and insulation materials. It uses PID temperature control and provides a timed end-of-test alarm.

Applicable standards: UL 758, UL 1581, UL 62, ASTM and GB methods.

Technical specifications:

1. Temperature range: ambient to 300°C.

2. Temperature uniformity: less than 1.5°C.

3. Timer: 0–9,999 hours.

4. Test medium: No. 2 lubricating oil or insulating oil; oil is not included.

5. Bath dimensions: 300 × 250 × 220 mm; six test cups.

6. External dimensions: 550 × 380 × 350 mm.

7. Power: AC 220 V, 50 Hz, 1,600 W.
